““Shopping List A breadboard (Jameco #2212218, Bitsbox #CN204) with at least 60 rows. Breadboard jumper wires (Jameco #2237044, Bitsbox #CN236)—you’ll need around 35 for this project. Standard hookup wire works, too. A standard 9 V battery to power the circuit. A 9 V battery clip (Jameco #11280, Bitsbox #BAT033) to connect the battery. A 555 timer IC (Jameco #904085, Bitsbox #QU001) to create the timing. A 10 kΩ resistor (Jameco #691104, Bitsbox #CR2510K) to set the game speed. A 100 kΩ resistor (Jameco #691340, Bitsbox #CR25100K) to set the game speed. A 1 µF capacitor (Jameco #768183, Bitsbox #CC006) to set the game speed. A 4017 decade counter IC (Jameco #12749, Bitsbox #QU020) to control the LEDs. Two standard blue LEDs (Jameco #2193889, Bitsbox #OP033) Two standard red LEDs (Jameco #333973, Bitsbox #OP002) A standard green LED (Jameco #34761, Bitsbox #OP003) Ten 100 Ω resistors (Jameco #690620, Bitsbox #CR25100R) for limiting the current to the LEDs. A 4011 NAND-gate IC (Jameco #12634, Bitsbox #QU018) to create the SR latch for starting and stopping the game. Two 1 kΩ resistors (Jameco #690865, Bitsbox #CR251K) to act as pull-up resistors for the start/stop circuit. Two push buttons (Jameco #119011, Bitsbox #SW087), one for resetting the game and one for playing.””
About This Quote
This interpretation was drafted with AI assistance. It is one reading of the quote, not the author's own explanation.
A detailed list of electronic components needed to build a 555‑timer based LED game circuit.
In simple terms: Component list for a DIY electronics project.
Key Takeaway
Gather parts before starting build.
Themes
electronics
DIY
project planning
Mood
practical
focused
Type
instructional
technical
When to use this quote
- building a hobby electronics kit
- classroom demonstration
- maker fair exhibit
Key Concepts
circuit design
component sourcing
prototyping
Questions to Reflect On
- Do you have all items in stock?
- How will you test the circuit as you assemble?
A Different Perspective
May overlook alternative cheaper parts or supply shortages.
